A588 Alloy Structural Steel Plate
ASTM A588 steel is a high-strength low-alloy structural steel section, steel plate and bar used for welded, riveted or bolted structures. These steels are mainly used in welded bridges and buildings where weight reduction or increased durability is required. In most environments, the atmospheric corrosion resistance of this steel is significantly better than that of carbon structural steel with or without the addition of copper.
Product Parameters
| Product Name | A588 Alloy Structural Steel Plate |
| Production Process | Hot Rolling, Cold Rolling |
| Material Standards | AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, etc. |
| Width | 100mm-3000mm |
| Length | 1m-12m, or Customized Size |
| Thickness | 0.1mm-400mm |
| Delivery Conditions | Rolling, Annealing, Quenching, Tempered or Standard |
| Surface Process | Ordinary, Wire Drawing, Laminated Film |
Chemical Composition
| A588 | C | Mn | P | S | Si | Ni | Cr | Cu | V |
| GradeA | 0.19% | 0.80-1.25% | 0.03% | 0.03% | 0.30-0.65% | 0.40% | 0.40-0.65% | 0.25-0.40% | 0.02-0.10% |
| GradeB | 0.20% | 0.75-1.35% | 0.03% | 0.03% | 0.15-0.50% | 0.50% | 0.40-0.70% | 0.20-0.40% | 0.01-0.10% |
| GradeC | 0.17% | 0.50-1.20% | 0.03% | 0.03% | 0.25-0.50% | 0.40% | 0.40-0.70% | 0.30-0.50% | – |
Mechanical Properties
| Thickness | Yield Strength(Ksi) | Tensile StrengthMin (ksi) | min. 2″ Elongation% | min. 8″ Elongation% |
| Below 4mm | 50 | 70 | 21 | 18 |
| 4in.-5 in. | 46 | 67 | 21 | – |
| 5in.-8 in. | 42 | 63 | 21 | – |
Scope of Application
ASTM A588 alloy steel has many applications: outdoor sculpture, crane, bridge, rail car, transmission tower, highway pole and shipbuilding.
Equivalent Material
| American Standard ASTM A588 | ASME SA588 | German Standard DIN, WNr | United Kingdom BS | Italy UNI | European Standard EN |
| A588 Grade A | SA588 Grade A | WTSt 52-3 | WR 50 C | Fe 510 D2K1 | S355J2G1W |
| China | USA | Germany | Japan | France | U.K. | internationality |
| GB3077 | AlSI | DIN | JIS | NE | BS | ISO |
| 20Mn2 | 1320
1221 |
20Mn5 | SMn21 | 20M5 | 150M19 | – |
| 30Mn2 | 1330 | 30Mn5 | SMn24 | 32M5 | 150M28 | – |
| 35Mn2 | 1335 | 36Mn5 | SMnl | 35M5 | 150M36 | – |
| 40Mn2 | 1340
1341 |
– | SMn2 | 40M5 | – | – |
| 45Mn2 | 1345 | 46Mn7 | SMn3 | 45M5 | – | – |
| 50Mn2 | 1052 | 50Mn7 | – | 55M5 | – | – |
| 20MnV | – | 20MnV6 | – | – | – | |
| 30Mn2MoW | – | — | – | – | – | |
| 27SiMn | – | 27MnSi5 | – | – | – | |
| 35SiMn | – | 37MnSi5 | – | 38MS5 | – | – |
| 42SiMn | – | 38MnSi4
46MnSi4 |
– | 38MS5 | – | – |
| 20SiMn2MoV | – | – | – | – | – | – |
| 25SiMn2MoV | – | – | – | – | – | – |
| 37SiMn2MoV | – | – | – | – | – | – |
| 40B | 14B35 | 35B2 | – | – | – | – |
| 45B | 50B46H | 45B2 | – | – | – | – |
| 50B | 14B50 | – | – | – | – | – |
| 4OM∏B | 15B41 | – | – | – | – | – |
| 45MnB | 15B48
50B44 |
– | – | – | – | – |
| 20Mn2B | – | – | – | – | – | – |
| 20MnMoB | 80B20 | – | – | – | – | – |
| 15MnVB | – | – | – | – | – | – |
| – | – | – | – | – | – | – |
| – | – | – | – | – | – | – |
| 20MnVB | – | – | – | – | – | – |
| 40MnVB | – | – | – | – | – | – |
| 20MnTiB | – | – | – | – | – | – |
| 25MnTiBRE | – | – | – | – | – | – |
| 2OSiMnVB | – | – | – | – | – | – |
| 15Cr | 5015
5115 |
15Cr3 | SCr21 | 12C3 | 523A14
523M15 |
– |
| 15CrA | – | – | – | – | – | – |
| 20Cr | 5120 | 20Cr4 | SCr22 | 18C3
18C4 |
527A19
527M20 |
683/11
20Cr4 20CrS4 |
| 30Cr | 5130 | 28Cr4 | SCr2 | 28C4
32C4 |
530A30
530A32 |
– |
| 35Cr | 5135 | 34Cr4
37Cr4 |
SCr3 | 38C4 | 530A36 | 683/8
3、 3a、 3b |
| 40Cr | 5140 | 38Cr4
41Cr4 |
SCr4 | 42C4 | 530A40
530M40 |
683/1
4、 4a^ 4b |
| 45Cr | 5145 | 42Cr4 | SCR5 | 45C4 | – | – |
| 50Cr | 5150
5152 |
– | – | 50C4 | En48 | – |
| 38CrSi | – | – | – | – | – | – |
| 12CrMo | 4119 | 13CrMo44 | – | 12CD4
15CD2 |
– | – |
| 15CrMo | ASTM
A-387Gr. B |
15CrMo5
16CrMo44 |
SCM21 | 15CD4. 05 | BS1653 | – |
| 20CrMo | 4118 | 20CrMo5
22CrMo4 |
SCM22 | 18CD4
20CD4 |
CDS 12
CDSllO |
– |
| 30CrMo | 4130 | 25CrMo4 | SCM2 | 30CD4 | CDS 13 | – |
| 30CrMoA | – | 32CrMol2
3ICRMo12 |
– | – | – | – |
| 35CrMo | 4135
4137 |
34CrMo4
35CrMo4 |
SCM3 | 35CD4 | 78A37 | 683/1
C35ea C35eb |
| 42CrMo | 4140
4142 |
41CrMo4
42CrMo4 |
SCM4 | 40CD4
42CD4 |
708M40
708A42 709M40 |
683/1
3 |
| 12CrMoV | – | – | – | – | – | – |
| 35CrMoV | – | 35CrMoV5 | – | – | – | – |
| 12CrlMoV | – | 13CrMoV4.2 | – | – | – | – |
| 25Cr2MoVA | – | 24CrMoV5.5 | – | – | – | – |
| 25Cr2MolVA | – | – | – | – | – | – |
| 20CR3MoWVA | – | 21CrVMoW12 | – | – | – | – |
| 38CrMoΛl | 6370 (ΛMS) | 34CrAlMo5
41CrAlMo7 |
SACM645 | 40CAD6.12 | 905M39 | 683/10
41CrAlMo74 |
| 20CrV | 6120 | 22CrV4 | – | 22CrV4 | – | – |
| 40CrV | 6140 | 42CrV | – | 42CrV4 | – | – |
| 50CrVA | 6150 | 50CrV4 | SUPlO | 50CV4 | 735A50 | – |
| 15CrMn | – | 16MnCr5 | – | 16MC5 | – | – |
| 20CrMn | 5120 | 20MnCr5 | SMC21 | 20MC5 | – | – |
| 40CrMn | 5140 | – | SMC3 | – | – | – |
| 20CrMnSi | – | – | – | – | – | |
| 25CrMnSi | – | – | SMKl | – | – | – |
| 30CrMnSi | – | – | – | – | – | – |
| 30CrMnSiA | – | – | – | – | – | – |
| 35CrMnSiA | – | – | SMK2 | – | – | – |
| 20CrMnMo | 4119 | 20CrMo5 | SCM23 | – | – | – |
| 40CrMnMo | 4140 | – | – | – | – | – |
| 20CrMnTi | – | – | SMK22 | – | – | – |
| 30CrMnTi | – | 30MnCrTi4 | – | – | – | – |
| 20CrNi | 3120 | 20NiCr6 | – | 20NC6 | 637A16
637M17 |
– |
| 40CrNi | 3140 | 46NiCr6 | SNCl | 35NC6 | 640A35
640M40 |
– |
| 45CrNi | 3145 | 45NiCr6 | – | – | – | – |
| 50CrNi | 3150 | – | – | – | – | – |
| 12CrNi2 | 3115 | 14NiCrlO | SNC21 | IONCll
14NC11 |
– | – |
| 12CrNi3 | 3310 | 13NiCrl2 | SNC22 | 10NC12
14NC12 |
655A12
655M13 |
– |
| 20CrNi3 | – | 22NiCrl4 | – | 20NC11 | – | – |
| 30CrNi3 | – | 28NiCrlO
31NiCrl4 |
SNC2 | 30NC11
30NC12 |
– | – |
| 37CrNi3 | – | 35NiCrl8 | SNC3 | 35NC15 | – | – |
| 12Cr2Ni4 | E3310 | 14NiCrl8 | – | 12NC15 | – | – |
| 20Cr2Ni4 | E3316 | 22NiCrl4 | – | 20NC14 | 659A15
659M15 |
– |
| 20CrNiMo | 8620
8720 |
20NiCrMo2
21NiCrMo2 |
– | 20NCD2 | 805A20
805M20 |
– |
| 40CrNiMoA | 4340
9840 |
36NiCrMo4
40NiCrMo6 |
SNCM8 | 35NCD5
40NCD3 |
817M40
816M40 |
– |
| 45CrNiMoVA | 4437 | – | SNCM9 | – | – | – |
| 18Cr2Ni4WA | ||||||
| 25Cr2Ni4WA |
